360mm Swing Slant Bed CNC Lathe Machine , 20m / Min Movement Computer Lathe Machine

Name: 360mm Swing Slant Bed CNC Lathe Machine 20m Min Movement Computer Lathe Machine
Brand: JOINT
Price: 1 USD

Buy cheap 360mm Swing Slant Bed CNC Lathe Machine , 20m / Min Movement Computer Lathe Machine product

Brand Name : JOINT

Model Number : HTC3627B

Certification : ISO 9001:2015

Place of Origin : CHINA

MOQ : 1 SET

Price : NEGOTIATION

Payment Terms : TT/LC/DA/DP

Supply Ability : 1000 SETS/YEAR

Delivery Time : NEGOTIATION

Packaging Details : WOODEN PALLTES / WOODEN CASE

Name : cnc lathe machine

Model : HTC3627B

Max swing diameter over table : 360mm

Max length of workpiece : 200mm

Spindle through hole diameter : 56mm

Z aixs limited travel : 270mm

Bed type : whole body slant type 45°

Net weight : 1850kgs

Contact Now

Max Swing Diameter 360mm Slant Type Cnc Lathe Machine Spindle Through Hole 56mm

Product Feature

1. X/ Z axis linear way , rapid feed is 20m/min

2. Taiwan high speed spindle, ensured the accuracy and high speed

3. Coulping ,bearing , ball screw and linear way are imported from German ,Japan and Taiwan famous Brand

4. Auto Lubrication system , Reduces wear and keep the accuracy

Specail Model

1. Great travel cnc lathe machine -- HTC3640

2. X axis one- side travel is 350mm ,the total travel is 700mm ,could equipped with more tools, fit for complex parts

3. Specail spindle bearing and X/Z axis bearings ,promoted the machine rigidity substantially, and the cutting force has been promoted about 50%

Specification of cnc lathe machine

Model	HTC3627B
Max swing diameter over table	360mm
Max swing diameter over carriages	120mm
Max length of workpiece	200mm
Spindle head	A-5(6")
Spindle motor	5.5KW
Spindle rotation speed	4200rpm
Spindle through-hole diameter	56mm
bar diameter	42mm
X axis limited travel	380mm
Z axis limited travel	270mm
Tool post	Gang tool /Four position electrical turret /six or eight position hydraulic turret
Height of tool turret center	63mm
X axis rapid movement	20m/min
Z axis rapid movement	20m/min
Bed type	whole body slant type 45°
Dimension	150012001700mm
Net weight	1850kgs

360mm Swing Slant Bed CNC Lathe Machine , 20m / Min Movement Computer Lathe Machine

Standard accessories

GSK Or Syntec or Fanuc controller

hydraulic three jaw chuck

5.5KW servo spindle motor

Taiwan spindle

Imported ball screw

Imported linear way
